M122NG Turbine Engine, 26 Lbs Thrust, From JetsMunt

Original price was: $379.00.Current price is: $98.99.

Nature-friendly materials, 100%.

Free Shipping Worldwide

Get the Best for Less

Safe and Secure Payments, Always

M122NG Turbine Engine, 26 lbs Thrust, from JetsMunt

The M122 NG is the engine of choice for the 2 meter class of sport models. 12.2kg packed in a small, lightweight body that can cover many jets options thanks to its great weight and size to power ratio.

Nominal thrust: 12.2kg (120 N) at 152,000 RPM
Idle thrust: 4N
Idle RPM: 40,000
Diameter: 90mm (3.5″)
Engine weight: 978g
Installed weight: 1.159g
Fuel: Kerosene/Diesel + 3% – 5% oil
Fuel consumptions: 340g/min
Start mode: Direct Kerosene

Includes engine and all ancillary accessories needed to run the engine, except the battery. Recommended 7.4v 2500mAh LiPo battery.

The power is adjustable from 5.5 to 12.2kg, which is perfect for installing a multitude of models and adapting the power to our aircraft. The successful M122 NG engine was the first to receive the new electronic system. Sensors and valves are installed inside the motor, simplifying installation. Starter and fuel pump motors are brushless, an industry first, only in JetsMunt!

The engine has only one fuel input directly from the pump, and a 3-wire electrical connection to the ecu that carries the battery power and a bidirectional digital bus. All measures and data from the engine are transmitted to the ecu in digital data format, using a high speed proprietary protocol specially developed for this application. The bus design allow a distance up to 1,5 meters from engine to ecu while keeping the generated noise by the bus to a very low level to not affect other devices nor to be affected by them.
